Port Tuban

Daerah : East Java

Terminal Khusus (Tersus) Tuban is a special petrochemical and fuel terminal located at Tanjung Awar-awar, Kecamatan Jenu, Kabupaten Tuban, East Java, jointly serving PT Pertamina Port & Logistics facilities and PT Trans Pacific Petrochemical Indotama (TPPI).

Location Tanjung Awar-awar, Desa Remen, Kecamatan Jenu, Kabupaten Tuban, East Java, Indonesia

Terminal Terminal Khusus (TERSUS) Tuban

Berth 3 Single Point Moorings (SPM) and 3 Jetties (Jetty 3–5, TPPI) — 6 berths total

Operation 24 Hours Operation

Vessel Min/Max 4,000 – 150,000 DWT; Min/Max 76 – 250 meter LOA

Timezone UTC +07:00 (Western Indonesia Time / WIB)

Overview

Terminal Khusus (Tersus) Tuban comprises three Single Point Moorings and three TPPI jetties handling fuel, condensate, LPG, and petrochemical products. The terminal has a sand, coral, and mud seabed, is subject to compulsory pilotage, and is jointly served by PT Pertamina Port & Logistics and PT Trans Pacific Petrochemical Indotama (TPPI).

Facilities | Services

Facilities

7 Tugboats (3,000–4,000 HP) and 3 Mooring Boats (150–220 HP)
Fire-fighting facility
Freshwater and bunker fuel supply via barge/tongkang
Warehouse / cargo storage (Gudang FT Tuban)
15 units of navigation aid (SBNP)

Oil spill response:

1,500-meter Oil Boom
3 Oil Skimmers
3 Oil Dispersant Pumps
Oil Sorbent
3 Oil Containment Bags

Services

Loading
Unloading
Bunkering (via barge)

Vessel Information

Depth at Berth 11 – 26 m LWS Channel 24 m
Pilotage Compulsory
Navigation Hazards: None specifically reporte

Seabed Type:

Sand
Coral
Mud

Port Regulations

ISPS Code Compliance

Both the Pertamina facility and the TPPI facility hold ISPS Code Comply status, each with a designated Port Facility Security Officer (PFSO).

Radio Communication

Vessels maintain radio contact with the terminal via VHF Channels 9, 12, 16, and 19 throughout their stay.

Safety Inspection

Vessels calling at the terminal are subject to safety inspection covering berthing, mooring, and cargo transfer arrangements.

Compulsory Pilotage

The terminal's waters are designated as Wajib Pandu (Compulsory Pilotage Area).

Pollution Prevention

The terminal maintains dedicated oil-spill response equipment and procedures for preventing marine pollution during cargo operations.

Map | Contact

Address:

Jl. Tanjung Awar-awar, Desa Remen, Kecamatan Jenu, Kabupaten Tuban, East Java, Indonesia

Phone:

0811 3110 054

Operator:

PT Pertamina Port & Logistics

Jetty Capacity:

SPM 150,000 DWT: 20,000 – 150,000 DWT, LOA up to 250 m, Depth 24 m
SPM 35,000 DWT: 12,000 – 35,000 DWT, LOA up to 182.5 m, Depth 15 m
SPM 150,000 DWT: 50,000 – 150,000 DWT, LOA 180 – 250 m, Depth 26 m
Jetty 3 – TPPI: 4,000 – 10,000 DWT, LOA 91 – 140 m, Depth (Pool) 11 m
Jetty 4 – TPPI: 10,000 – 40,000 DWT, LOA 76 – 187 m, Depth (Pool) 11 m
Jetty 5 – TPPI: 10,000 – 40,000 DWT, LOA 76 – 187 m, Depth (Pool) 11 m

Flow Rate:

SPM 35,000 DWT: 3,500 KL/hour at 7 Kg/cm²
SPM 150,000 DWT: 1,100 KL/hour at 7 Kg/cm²
SPM 150,000 DWT – TPPI: 4,000 KL/hour at 4 Kg/cm²
Jetty 3 – TPPI: 90 – 400 KL/hour depending on product at 7 Kg/cm²
Jetty 4 – TPPI: 90 – 1,200 KL/hour depending on product at 7 Kg/cm²
Jetty 5 – TPPI: 400 – 875 KL/hour depending on product at 7 Kg/cm²

Coordinates:

SPM 150,000 DWT: 06°42'48"S, 111°56'21"E

Download Port Info Contact PTK Open Map
